Axes X1,Y1,Z1,C1,X2,Y2,Z2,C2 Encoder / axis motor technique Absolute serial Motor type (axes and guide bush) Synchronous (AC) Motor type (spindles) Asynchronous (AC) Main spindle Max. bar capacity mm 23 (25.4) Standard workpiece length with rotating guide bush mm 220 Spindle rotation speed rpm 0-10,000 Spindle power kW 8.2 (10.5) Max. torque Nm 26 Platen Max. number of turning tools 10 Turning tool section 16 x 16 Positions for rotating tools (S11) 4 Rotating tool speed of rotation rpm 5000 Rotating tool power (S11 / S21) kW 0.75 B-axis Number of rotating tool positions S21 (op / cop) 4 / 4 Number of fix frontal tools (op / cop) 4 HF spindle Option Thread whirling device Option Rotating tool speed of rotation rpm 9000 Rotating tool power (S11 / S21) kW 0.75 / 1 Counter spindle Max. bar capacity mm 25.4 Insertion length of workpiece into spindle mm 120 Max standard output length of workpiece mm 120 Spindle rotation speed rpm 0-10,000 Spindle power kW 8.2 (10.5) Max. torque Nm 26 Number of tool positions next to the counter spindle 2 Counter operation Number of tool positions 8 Positions for rotating tools 4 Rotating tool speed of rotation rpm 5000 Rotating tool power kW 0.75 Total number of tools 36 Operation / counter-operation tool distribution 23/13 Cutting oil tray capacity Liter 200 Coolant Pump Power kW 0.44 Dimensions are only approx:L x W x H (approx.) mm 2710 x 1270 x 1990 86″ x 50″ x 79″ Weight kg 3550 7827 lbs
